background image
Obsolete
Product(s)
- Obsolete
Product(s)
Obsolete
Product(s)
- Obsolete
Product(s)
ST7LITEUS2, ST7LITEUS5
Supply, reset and clock management
35/136
6.4
Reset sequence manager (RSM)
6.4.1
Introduction
The reset sequence manager includes three reset sources as shown in Figure 12:
●
External RESET source pulse
●
Internal LVD reset (low voltage detection)
●
Internal WATCHDOG reset
Note:
A reset can also be triggered following the detection of an illegal opcode or prebyte code.
Refer to Figure 12.
These sources act on the RESET pin and it is always kept low during the delay phase.
The RESET service routine vector is fixed at addresses FFFEh-FFFFh in the ST7 memory
map.
The basic reset sequence consists of 3 phases as shown in Figure 11:
●
Active phase depending on the reset source
●
64 CPU clock cycle delay
●
RESET vector fetch
Caution:
When the ST7 is unprogrammed or fully erased, the Flash is blank and the RESET vector is
not programmed. For this reason, it is recommended to keep the RESET pin in low state
until programming mode is entered, in order to avoid unwanted behavior.
The 64 CPU clock cycle delay allows the oscillator to stabilise and ensures that recovery
has taken place from the Reset state.
The RESET vector fetch phase duration is 2 clock cycles.
Figure 11.
Reset sequence phases
RESET
Active phase
INTERNAL RESET
64 CLOCK CYCLES
FETCH
VECTOR
Obsolete
Product(s)
- Obsolete
Product(s)
