background image
P9221-R Datasheet
© 2017 Integrated Device Technology, Inc.
11
April 4, 2017
Symbol
Description
Conditions
Min
Typical
Max
Units
tSU:STA
Set-up Time for Repeated
START Condition
0.6
µs
tBUF
Bus Free Time Between
STOP and START
Condition
1.3
µs
CB
Capacitive Load for each
Bus Line
150
pF
CI
SCL, SDA Input
Capacitance
5
pF
Thermal Shutdown
TSD
Thermal Shutdown
Rising[b]
140
°C
Falling
120
°C
[a] Do not externally load. For internal biasing only.
[b] If the die temperature exceeds 130°C, the Thermal_SHTDN_Status flag is set and an end power transfer (EPT) packet is sent (see Table 11).
