Unit：mm

CM02B Series

http://www.ddknet.co.jp

◎

Specifications and/or dimensions in this catalog are subject to change without notice. ◎ Your checking the latest specifications with our drawings would be highly appreciated.

○Dust Cap for Plug & Plug Receptacle

○Dust Cap for Jack & Receptacle

5

Metal Cap

Copper Alloy/Nickel Plating

Metal Cap

Copper Alloy/Nickel Plating

Plastic Cap

Plastic/Clear

Metal Cap

Aluminum Alloy

Plastic Cap

Plastic/Black

Plastic Cap

Plastic/Clear

13

6.9

Ｍ12×1 Thread

8.5

φ3.2

18

13

100

12

10

8.7

14.3

M12×1Thread

15

18

P/N

CM01-P-CAP-CF

P/N

CM01-R-CAP-CF

P/N

CM01-CAP

P/N

CM01-R-CAP(D1)

P/N

CM02B-J-DC

P/N

CM04-PR-DC
