KEMET Part Number: ESD-R-15C

(UECESDR15C0000)

EMI Cores, Commercial Grade, ESD-R

Dimensions

D

15.2mm MAX

D2

10.5mm MAX

T

12.5mm MAX

General Information

Style: Round

Brand: NEC-Tokin

Series: ESD-R

Cable Type: Round Cable

Description:

EMI Core Solid, For Round

Cables, Toroidal Cores, Coated

Type

RoHS: Yes

Case Color: Blue

Toroidal: ESD-R-15C-1

Materials: Mn-Zn & Ni-Zn

Specifications

Effective Frequency: 300 MHz (FM Band Range)

Statements of suitability for certain applications are based on our knowledge of typical operating conditions for such applications, but are not intended to constitute - and

we specifically disclaim - any warranty concerning suitability for a specific customer application or use. This Information is intended for use only by customers who have the

requisite experience and capability to determine the correct products for their application. Any technical advice inferred from this Information or otherwise provided by us

with reference to the use of our products is given gratis, and we assume no obligation or liability for the advice given or results obtained.
