2015-08-07

1

2015-08-07

CERAMOS Gen 4.H

Datasheet

Version 1.0

CW CBLPM1.E1

Highly efficient lightsource, slim package design

Hocheffiziente Lichtquelle, niedrige Bauteilhöhe

Features:

Besondere Merkmale:

•

Package: SMD ceramic package with silicone

resin

•

Gehäusetyp: SMD Keramik Gehäuse mit

Silikonverguss

•

Technology: ThinGaN (UX:3)

•

Technologie: ThinGaN (UX:3)

•

Viewing angle at 50 % I

V: 120° (Lambertian

Emitter)

•

Abstrahlwinkel bei 50 % I

V: 120° (Lambertscher

Strahler)

•

Color: Cx = 0.36, Cy = 0.37 acc. to CIE 1931

(white); CRI (typ.) = 82; CRI (min.) = 80

•

Farbe: Cx = 0.36, Cy = 0.37 nach CIE 1931 (weiß);

CRI (typ.) = 82; CRI (min.) = 80

•

ESD - withstand voltage: 2 kV acc. to

ANSI/ESDA/JEDEC JS-001 (HBM, Class 2); 8 kV

acc. to IEC 61000-4-2, level 4 (contact discharge)

•

ESD - Festigkeit: 2 kV nach ANSI/ESDA/JEDEC

JS-001 (HBM, Klasse 2); 8 kV nach IEC 61000-4-2,

level 4 (Kontaktentladung)

Applications

Anwendungen

•

Camera Flash and Video Light

•

Blitzlicht für Kameras/ Videoleuchte

•

Torch Light

•

Taschenlampe
