Data Sheet

ADL5304

Rev. A | Page 5 of 32

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

VPOS

+6 V

VNEG

−6 V

Input Current to INUM, IDEN

20 mA

Thermal Data, 2-Layer JEDEC Board No Air

Flow (Exposed Pad Soldered to PCB)

θJA

61.6°C/W

θJC

1.2°C/W

Maximum Power Dissipation (Exposed

Pad Soldered to PC Board)

0.6 W

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
