background image
Specification
NET2890 USB Interface Controller
____________________________________________________________________________________
NetChip Technology, Inc., 1999
335 Pioneer Way, Mountain View, California 94041
TEL (650) 526-1490
FAX (650) 526-1494
http://www.netchip.com
Rev 2.0, Draft 9, July 16, 1999
53
5.6.12 (Index 15h; EPBPKTSIZMSB) EPB Max Packet Size (MSB)
Bits
Description
Read
Write
Default
Value
7:2
Reserved
Yes
No
0
1:0
EPB Max Packet Size MSB. This field provides the most significant bits of the
Endpoint B Maximum Packet Size.
Yes
Yes
0
5.6.13 (Index 16h; EPCPKTSIZLSB) EPC Max Packet Size (LSB)
Bits
Description
Read
Write
Default
Value
7:0
EPC Max Packet Size LSB. This field provides the least significant bits of the
Endpoint C Maximum Packet Size.
Yes
Yes
64
5.6.14 (Index 17h; EPCPKTSIZMSB) EPC Max Packet Size (MSB)
Bits
Description
Read
Write
Default
Value
7:2
Reserved
Yes
No
0
1:0
EPC Max Packet Size MSB. This field provides the most significant bits of the
Endpoint C Maximum Packet Size.
Yes
Yes
0
5.6.15 (Index 18h; EPDPKTSIZLSB) EPD Max Packet Size (LSB)
Bits
Description
Read
Write
Default
Value
7:0
EPD Max Packet Size LSB. This field provides the least significant bits of the
Endpoint D Maximum Packet Size.
Yes
Yes
64
5.6.16 (Index 19h; EPDPKTSIZMSB) EPD Max Packet Size (MSB)
Bits
Description
Read
Write
Default
Value
7:2
Reserved
Yes
No
0
1:0
EPD Max Packet Size MSB. This field provides the most significant bits of the
Endpoint D Maximum Packet Size.
Yes
Yes
0
5.6.17 (Index 20h; F0_AETH) FIFO 0 Almost Empty Threshold Register
Bits
Description
Read
Write
Default
Value
7:5
Reserved
Yes
No
0
4:0
FIFO Almost Empty Threshold. This register determines the threshold at which the
FIFO almost empty status bit is set. The threshold is in terms of bytes. For Endpoint
0, this value can range from 0 to 16.
Yes
Yes
0
