2011/09/06

Rev.A.3

4

EM8800A

Supply voltage, VCC--------------------------------------------------------------- -0.3V to 24V

GATE----------------------------------------------------------------------------------

-0.3V to 24V

Other pins---------------------------------------------------------------------------

0.3V to 6V

Power Dissipation, PD @ TA = 25°C, SOP-8 -------------------------------- 0.909W

Package Thermal Resistance, ΘJA, SOP-8 (Note 2)------------------------

110°C/W

Junction Temperature------------------------------------------------------------

150°C

Lead Temperature (Soldering, 10 sec.)----------------------------------------

260°C

Storage Temperature Range-----------------------------------------------------

-65°C to 150°C

ESD susceptibility (Note3)

HBM (Human Body Mode)------------------------------------------------------

2kV

MM (Machine Mode)------------------------------------------------------------

200V

Junction Temperature

------------------------------------------------------

-40°C to 125°C

Ambient Temperature

------------------------------------------------------

-40°C to 85°C

Electrical Characteristics

Parameter

Symbol

Test Conditions

Pin

Min

Typ

Max

Units

VCC Section

VCC OVP Protect voltage

21

22

23.5

V

VCC On Threshold Voltage

9.0

9.75

10.5

V

VCC Off Hysteresis Voltage

1.5

V

Current Consumption in Latch Mode

0.6

1.2

mA

Current Consumption in Start-up

0.05

0.1

mA

Current Consumption in Device Disable

VCC=12V,

0.6

1.2

mA

Current Consumption in Device Switching

1.5

2.35

mA

Gate Section

Rising Time

80

140

ns

Falling Time

30

60

ns

Output Voltage Low

20mA

1

V

Output Voltage High

20mA

11

V

Current-Sense Section

Maximum Internal Current Set-point

0.97

1

1.03

V

Leading Edge Blanking Time

400

550

700

ns

Propagation Delay Time

Cgate=1nF

100

150

200

ns

Internal Soft-Start Period

2

ms
