TLF5322

January 1988

MM54HC190MM74HC190 Synchronous

Decade UpDown Counters with Mode

Control MM54HC191MM74HC191

Synchronous Binary UpDown Counters

with Mode Control

General Description

These high speed synchronous counters utilize advanced

silicon-gate CMOS technology They possess the high noise

immunity and low power consumption of CMOS technology

along with the speeds of low power Schottky TTL

These circuits are synchronous reversible updown count-

ers The MM54HC191MM74HC191 are 4-bit binary count-

ers and the MM54HC190MM74HC190 are BCD counters

Synchronous operation is provided by having all flip-flops

clocked simultaneously so that the outputs change simulta-

neously when so instructed by the steering logic This mode

of operation eliminates the output counting spikes normally

associated with asynchronous (ripple clock) counters

The outputs of the four master-slave flip-flops are triggered

on a low-to-high level transition of the clock input if the

enable input is low A high at the enable input inhibits count-

ing The direction of the count is determined by the level of

the downup input When low the counter counts up and

when high it counts down

These counters are fully programmable that is the outputs

may be preset to either level by placing a low on the load

input and entering the desired data at the data inputs The

output will change independent of the level of the clock in-

put This feature allows the counters to be used as modulo-

N dividers by simply modifying the count length with the

preset inputs

Two outputs have been made available to perform the cas-

cading function ripple clock and maximumminimum count

The latter output produces a high-level output pulse with a

duration approximately equal to one complete cycle of the

clock when the counter overflows or underflows The ripple

clock output produces a low-level output pulse equal in

width to the low-level portion of the clock input when an

overflow or underflow condition exists The counters can be

easily cascaded by feeding the ripple clock output to the

enable input of the succeeding counter if parallel clocking is

used or to the clock input if parallel enabling is used The

maximumminimum count output can be used to accom-

plish look-ahead for high-speed operation

Features

Y

Level changes on Enable or DownUp can be made re-

gardless of the level of the clock input

Y

Wide power supply range 2 – 6V

Y

Low quiescent supply current 80 mA maximum

(74HC Series)

Y

Low input current 1 mA maximum

Connection Diagram

Dual-In-Line Package

TLF5322 – 1

Top View

Load

Enable

Down

Clock

Function

GUp

HL

L

u

Count Up

HL

H

u

Count Down

L

X

X

X

Load

H

H

X

X

No Change

Order Number MM54HC190191 or MM74HC190191
