background image
TOPWAY
LCD Module User Manual
LM6800AFW-5
URL: www.topwaydisplay.com
www.topwaysz.com
Document Name: LM6800AGW-6-Manual-Rev0.1.DOC
Page: 4 of 10
1.4
Terminal Functions
Pin
No.
Pin
Name
I/O
Descriptions
1
VSS
Power Negative Power Supply, Ground (0V)
2
VDD
Power Positive Power Supply
3
V0
Input
LCD Contrast reference
4
VOUT Output Power Booster output for V0
5
RS
Input
RS = H; DB0 – DB7 = Display RAM data
RS = L; DB0 – DB7 = Instruction data
6
R/W
Input
7
E
Input
In read mode
R/W = H;
Data read form the LCD module,
data appears at DB0 – DB7 and can be read by the host
while, E = H and the device is being selected
In write mode
R/W = L;
Data write to the LCD module,
data appears at DB0 – DB7 will be written into the LCD module
at E = H L and device is being selected
8
DB0
I/O
:
:
:
15
DB7
I/O
Data bus:
Three state I/O terminal for display data or instruction data
16
CSA
Input
17
CSB
Input
18
CSC
Input
Chip selection, enable access to each section of the LCD module
CSC CSB CSA
Function
0
0
0
Enable access of the Left-Most Section (64 column)
of the LCD module
0
0
1
Enable access of the Middle-Left Section (64 column)
of the LCD module
0
1
0
Enable access to the Middle-Right Section (64 column)
of the LCD module
0
1
1
Enable access to the Right-Most Section (64 column)
of the LCD module
1
x
x
Disable all the access to the LCD module
19
/RST
Input
Reset signal
/RST = L,
Display off
display start line register becomes 0
no command or instruction data could be accepted
/RST = H,
Normal running
20
BLA
Power Positive Power Supply for LED backlight
