TAI-TECH

P3

5. Specification

Part Number

Inductance

L0 (uH)±20%

@ 0 A

Rated current

DCR

(mΩ)

@25℃

±

Tempetature

current

I rms (A)

Saturation

current

I sat (A)

HPC4030NF-R68M

0.68

4.60

6.80

10

HPC4030NF-1R0M

1.00

4.20

5.30

14

HPC4030NF-1R5M

1.50

3.40

4.90

20

HPC4030NF-2R2M

2.20

3.00

4.90

30

HPC4030NF-3R3M

3.30

2.40

3.30

40

HPC4030NF-4R7M

4.70

2.05

2.90

60

HPC4030NF-5R6M

5.60

1.95

2.60

65

HPC4030NF-6R8M

6.80

1.80

2.75

90

HPC4030NF-8R2M

8.20

1.60

2.10

90

HPC4030NF-100M

10.0

1.50

2.00

100

HPC4030NF-120M

12.0

1.30

1.80

135

HPC4030NF-150M

15.0

1.20

1.70

190

HPC4030NF-180M

18.0

1.10

1.50

200

HPC4030NF-220M

22.0

1.00

1.30

225

HPC4030NF-330M

33.0

0.85

1.10

330

HPC4030NF-470M

47.0

0.72

0.95

445

Note:

2. Testing Instrument : HP4284A,CH11025,CH3302,CH1320 ,CH1320S LCR METER / Rdc:CH502BC MICRO OHMMETER.

3. Heat Rated Current (Irms) will cause the coil temperature rise approximately Δt of 40℃.

4. Saturation Current ( Isat ) will cause L0 to drop approximately 30%.

5. The part temperature (ambient + temp rise) should not exceed 125℃under worst case operating conditions.Circuit design,component,PCB trace size and

thickness,airflow and other cooling provisions all affect the part temperature. Part temperature should be verified in the end application.

6. Special inquiries besides the above common used types can be met on your requirement.
