MODEL: AD3V

AD3V SPECIFICATIONS

ES-1389 Rev.24 Page 5/9

https://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm [inch]

3

4

5

6

2

1

8

7

50 (1.97)

103 (4.06)

123 (4.84)

[3.3 (.13)]

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

15 (.59) deep

8–M3.5

SCREW

•When mounting, no extra space is needed between units.

16

(.63)

55 (2.17) min.

TERMINAL ASSIGNMENTS unit: mm (inch)

5

6

2

1

8

7

3

4

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.
