Crystal-less Two Output PCIe Clock Generator

Output Clock Frequencies

Table 2 lists the standard default frequency configurations and the associated ordering information

to be used in conjunction with the ordering code. Customer defined combinations are available.

Table 2. Pre-programmed output frequency pairs

Ordering Info

CLK 1

(MHz)

CLK 2

(MHz)

R0001

25.0000

25.0000

RXXXX

-

-

DSC511-03

Packing

T: Tape & Reel

: Tube

D I 2

Package

D: 2520 6pin

Temp Range

E: -20 to 70

I: -40 to 85

L: -40 to 105

M: -55 to 125

Stability

1: ±50ppm

2: ±25ppm

5: ±10ppm

T

Frequency

Rxxxx

R0001

-
