EVK-R4 データシート(PDF) 7 Page - u-blox AG |
|
|
|||||||||||||||||||||||||||||
EVK-R4 データシート(HTML) 7 Page - u-blox AG |
|
|
7 / 31 page  EVK-R4 - User guide UBX-16029216 - R08 Starting up Page 7 of 31 C1-Public SIM card holder J300 Cellular power-ctrl SW302 GND 9 – 18 V Power input J400 Cellular adapter board DL400 Main power switch SW400 DL401 SARA-R422M8S cellular module DIL B2B connector J300 DIL B2B connector J301 GND NEO-M8N GNSS antenna connector J208 NEO-M8N GNSS module GNSS adapter board Cellular VCC supply jumper J404 Cellular USB (Single UART) J501 Cellular RS232 (Single UART) J500 DL501 DL403 DL405 GNSS USB J102 SW403 SW401 DL404 SW300 SW304 SW204 DS132 DS118 DS124 DS121 DS107 DS105 DS109 DS103 DS500 DS501 GND GND BT200 Cellular native USB J105 DS100 DS201 DS139 Cellular antenna connector (ANT) J106 SARA-R422M8S GNSS antenna connector J112 Cellular USB (Two UARTs) J201 Cellular VCC supply jumper J109 J248 Figure 3: Overview of the evaluation kit for SARA-R422M8S modules |
|
