DS198 LUXEON CZ Color Line Product Datasheet 20210826 ©2021 Lumileds Holding B.V. All rights reserved.
20
Radiation Pattern Characteristics
Figure 5 . Typical radiation pattern for LUXEON CZ Red, Red-Orange, PC Amber, Green,
Cyan, Blue, Royal Blue and White at 350mA, T
j=85°C .
White
Blue
Green and Cyan
PC Amber
Royal Blue
Red and Red-Orange
Figure 6 . Typical polar radiation pattern for LUXEON CZ Red, Red-Orange, PC Amber, Green,
Cyan, Blue, Royal Blue and White at 350mA, T
j=85°C .
White
Blue
Green and Cyan
PC Amber
Royal Blue
Red and Red-Orange
