ADL5387
Data Sheet
Rev. C | Page 10 of 27
0
–25
–20
–15
–10
–5
0
2000
1800
1600
1400
1200
1000
800
600
400
200
RF FREQUENCY (MHz)
Figure 21. RF Port Return Loss vs. RF Frequency, Measured on
Characterization Board through ETC1-1-13 Balun with 120 nH Bias Inductors
–20
–30
–40
–50
–60
–70
–80
–90
–100
0
2000
1800
1600
1400
1200
1000
800
600
400
200
INTERNAL 1xLO FREQUENCY (MHz)
1xLO
2xLO
Figure 22. LO-to-RF Leakage vs. Internal 1xLO Frequency
–20
–40
–60
–80
–100
–120
0
2000
1800
1600
1400
1200
1000
800
600
400
200
RF FREQUENCY (MHz)
Figure 23. RF-to-LO Leakage vs. RF Frequency
0
–30
–25
–20
–15
–10
–5
0
4000
3500
3000
2500
2000
1500
1000
500
FREQUENCY (MHz)
Figure 24. Single-Ended LO Port Return Loss vs.
LO Frequency, LOIN AC-Coupled to Ground
