Ordering information

Table 21. Ordering information scheme

Example:

M24

C02

-W

MC

6

T

P

Device type

M24 = I2C serial access EEPROM

Device function

C01 =1 Kbit (128 x 8 bit)

C02 =2 Kbit (256 x 8 bit)

Operating voltage

W = VCC = 2.5 V to 5.5 V

R = VCC = 1.8 V to 5.5 V

F = VCC = 1.6 or 1.7 V to 5.5 V

Package(1)

MN = SO8N (150 mil width)

DW = TSSOP8 (169 mil width)

MC = UFDFPN8 (DFN8)

MH = UFDFPN5 (DFN5)

Device grade

6 = Industrial: device tested with standard test flow over -40 to 85 °C

Option

T = Tape and reel packing

blank = tube packing

Plating technology

P or G = RoHS compliant and halogen-free (ECOPACK2)

1. All packages are ECOPACK2 (RoHS-compliant and free of brominated, chlorinated and antimony-oxide flame retardants).

Note:

For a list of available options (memory, package, and so on) or for further information on any aspect of this

device, contact your nearest ST sales office.

Note:

Parts marked as “ES”, “E” or accompanied by an Engineering Sample notification letter, are not yet qualified and

therefore not approved for use in production. ST is not responsible for any consequences resulting from such

use. In no event will ST be liable for the customer using any of these engineering samples in production. ST

Quality has to be contacted prior to any decision to use these Engineering samples to run qualification activity.
