8

DC and AC parameters

This section summarizes the operating and measurement conditions, and the DC and AC characteristics of the

device.

Table 5. Operating conditions (voltage range W)

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply voltage

2.5

5.5

V

TA

Ambient operating temperature

-40

85

° C

fC

Operating clock frequency

-

400

kHz

Table 6. Operating conditions (voltage range R)

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply voltage

1.8

5.5

V

TA

Ambient operating temperature

-40

85

° C

fC

Operating clock frequency

-

400

kHz

Table 7. Operating conditions (voltage range F)

Symbol

Parameter

Min.

Max.

Unit

VCC

Supply voltage

1.60

1.65

1.70

5.5

V

TA

Ambient operating temperature: READ

-40

-40

-40

85

° C

Ambient operating temperature: WRITE

0

-20

-40

85

fC

Operating clock frequency

-

-

-

400

kHz

Table 8. AC measurement conditions

Symbol

Parameter

Min.

Max.

Unit

Cbus

Load capacitance

-

100

pF

-

SCL input rise/fall time, SDA input fall time

-

50

ns

-

Input levels

0.2 VCC to 0.8 VCC

V

-

Input and output timing reference levels

0.3 VCC to 0.7 VCC

M24C16-W M24C16-R M24C16-F

DC and AC parameters

DS9194 - Rev 11

page 16/40
