Catalog | ABB general purpose drives ACS310 5

Powerful set of pump and fan features

Integrated and preprogrammed features like

pump cleaning, pipefill, inlet/outlet pressure

supervision and detection of under or overload

improve system reliability and lifetime. Built-in

PFC feature can eliminate the need for an

external programmable logic controller (PLC).

FlashDrop tool

FlashDrop is a powerful palm sized drive

configuration tool that copies a pre-defined

drive parameter set into a drive in 2 seconds

without a power connection to the drive.

Remote monitoring

Optional SREA-01 module enables

remote monitoring and access to

drive’s parameters and process via web

browser. It enables sending log files,

alarms and events by E-mail and SMS.

Additionally SREA-01 offers Modbus

TCP connectivity to ACS310.

Internal Modbus EIA-485 connection

Built-in terminals and connectivity for

Modbus RTU as standard enables the

system control and monitoring in the most

user friendly and cost effective way.

Relay extension module MREL-01

The optional MREL-01 module offers

three additional relay outputs. The

outputs can be configured for different

functions by setting selected parameters

eg, for multipump/-fan control.
