9 / 28 page  Catalog | ABB general purpose drives ACS310 9 Technical data Mains connection Voltage and power range 1-phase, 200 to 240 V ± 10% 0.37 to 2.2 kW (0.5 to 3 hp) 3-phase, 200 to 240 V ± 10% 0.37 to 11 kW (0.5 to 15 hp) 3-phase, 380 to 480 V ± 10% 0.37 to 22 kW (0.5 to 30 hp) Frequency 48 to 63 Hz Motor connection Voltage 3-phase, from 0 to Usupply Frequency 0 to 500 Hz Continuous loading capability I 2N maximum continuous output current at ambient temperature of +40 °C. No overloadability, derating 1% for every additional 1 °C up to 50 °C. I LD continuous output current at max ambient temperature of +50 °C. 10% overloadability for one minute every ten minutes. At start 1.6 x I 2N for 2 s Switching frequency Default Selectable 4 kHz 4 to 16 kHz with 4 kHz steps Acceleration time 0.1 to 1800 s Deceleration time 0.1 to 1800 s Motor control method Scalar U/f Environmental limits Ambient temperature -10 to 50 oC (14 to 122 oF), no frost allowed Altitude Output current Rated current available at 0 to 1000 m (0 to 3281 ft) reduced by 1% per 100 m (328 ft) over 1000 to 2000 m (3281 to 6562 ft) Relative humidity Lower than 95% (without condensation) Degree of protection IP20/optional NEMA 1 enclosure Enclosure colour NCS 1502-Y, RAL 9002, PMS 420 C Contamination levels Transportation Storage Operation IEC721-3-3 No conductive dust allowed Class 1C2 (chemical gases) Class 1S2 (solid particles) Class 2C2 (chemical gases) Class 2S2 (solid particles) Class 3C2 (chemical gases) Class 3S2 (solid particles) Product compliance Low Voltage Directive 2006/95/EC Machinery Directive 2006/42/EC EMC Directive 2004/108/EC Quality assurance system ISO 9001 Environmental system ISO 14001 UL, cUL, CE, C-Tick and GOST R approvals RoHS compliant Programmable control connections Two analog inputs Voltage signal Unipolar Bipolar Current signal Unipolar Bipolar Resolution Accuracy 0 (2) to 10 V, Rin > 312 kΩ -10 to 10 V, Rin > 312 kΩ 0 (4) to 20 mA, Rin = 100 Ω -20 to 20 mA, Rin = 100 Ω 0.1% ± 1% One analog output 0 (4) to 20 mA, load < 500 Ω Auxiliary voltage 24 V DC ± 10%, max. 200 mA Five digital inputs Input impedance 12 to 24 V DC with internal or external supply, PNP and NPN, pulse train 0 to 16 kHz 2.4 kΩ One relay output Type Maximum switching voltage Maximum switching current Maximum continuous current NO + NC 250 V AC/30 V DC 0.5 A/30 V DC; 5 A/230 V AC 2 A rms One digital output Type Maximum switching voltage Maximum switching current Frequency Resolution Accuracy Transistor output 30 V DC 100 mA/30 V DC, short circuit 10 Hz to 16 kHz 1 Hz 0.2% Serial communication Fieldbus Cable Termination Isolation Transfer rate Communication type Protocol Modbus EIA-485, embedded Shielded twisted pair, impedance 100 to 150 ohms Daisy-chained bus, without dropout lines Bus interface isolated from drive 1.2 to 76.8 kbit/s Serial, asynchronous, half duplex Modbus Chokes AC input chokes External option For reducing THD in partial loads and to comply with EN/IEC 61000-3-12 AC output chokes External option To achieve longer motor cables |
|
|
