E5CD/E5CD-B

Specifications

Ratings

*There can be up to four set points if event inputs are used to select them.

Power supply voltage

A in model number: 100 to 240 VAC, 50/60 Hz

D in model number: 24 VAC, 50/60 Hz; 24 VDC

Operating voltage range

85% to 110% of rated supply voltage

Power consumption

Models with option selection of 000:5.2 VA max. at 100 to 240 VAC, and 3.1 VA max. at 24 VAC or 1.6 W max.

at 24 VDC

All other models: 6.5 VA max. at 100 to 240 VAC, and 4.1 VA max. at 24 VAC or 2.3 W max. at 24 VDC

Sensor input

Temperature input

Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II

Platinum resistance thermometer: Pt100 or JPt100

Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C

Analog input

Current input: 4 to 20 mA or 0 to 20 mA

Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V

Input impedance

Current input: 150

Ω max., Voltage input: 1 MΩ min.

(Use a 1:1 connection when connecting the ES2-HB/THB.)

Control method

ON/OFF control or 2-PID control (with auto-tuning)

Control

output

Relay output

SPST-NO, 250 VAC, 3 A (resistive load), electrical life: 100,000 operations, minimum applicable load: 5 V, 10

mA (reference value)

Voltage output

(for driving SSR) Output voltage: 12 VDC ±20% (PNP), max. load current: 21 mA, with short-circuit protection circuit

Linear current

output

4 to 20 or 0 to 20 mA DC, Load: 500

Ω max., Resolution: Approx. 10,000

Auxiliary

output

Number of

outputs

Output

specifications

SPST-NO relay outputs: 250 VAC, E5CD: 3 A (resistive load), E5CD-B: 2 A (resistive load)

Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference values)

Event

input

Number of inputs 2

External contact

input

specifications

Contact input: ON: 1 k

Ω max., OFF: 100 kΩ min.

Non-contact input: ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.

Current flow: Approx. 7 mA per contact

Transfer

Output

Number of

outputs

1 (depends on model): Transfer output type

Output

specifications

Current output: 4 to 20 mA DC, Load: 500

Ω, Resolution: Approx. 10,000

Linear voltage output: 1 to 5 V DC, Load: 1 k

Ω min., Resolution: Approx. 10,000

Setting method

Digital setting using front panel keys

Indication method

11-segment digital display, individual indicators, and bar display

Character height: PV: 14.9 mm, SV: 7.1 mm

Multi SP

Up to eight set points (SP0 to SP7) can be saved and selected using the event inputs, key operations, or serial

communications.

Bank switching

None

Other functions

Adaptive control, automatic filter adjustment, water-cooling output adjustment, indication data (power ON time

monitor, ambient temperature monitor, and control output ON/OFF count monitors), parameter masking,

operation after power ON, manual output, heating/cooling control, loop burnout alarm, SP ramp, other alarm

functions, heater burnout (HB) alarm (including SSR failure (HS) alarm), 40% AT, 100% AT, MV limiter, input

digital filter, robust tuning, PV input shift, run/stop, protection functions, extraction of square root, MV change

rate limit, logic operations, temperature status display, simple programming, moving average of input value, and

display brightness setting

Ambient operating

temperature

−10 to 55°C (with no condensation or icing),

For 3-year warranty:

−10 to 50°C with standard mounting (with no condensation or icing)

Ambient operating humidity

25% to 85%

Storage temperature

−25 to 65°C (with no condensation or icing)

Altitude

2,000 m max.

Recommended fuse

T2A, 250 VAC, time-lag, low-breaking capacity

Installation environment

Overvoltage category II, Pollution Degree 2 (EN/IEC/UL 61010-1)
