L6393
Electrical data
7/20
4.3
Recommended operating conditions
Table 6.
Recommended operating conditions
Symbol
Pin
Parameter
Test condition
Min
Max
Unit
Vout
12
Output voltage (1)
1.
If the condition TBD V < Vboot - Vout < TBD V and Vboot < TBD V are guaranteed, Vout can range from TBD
V to 580 V
580
V
VBS
(2)
2.
VBS = Vboot -Vout
14
Floating supply voltage (1)
TBD
TBD
V
fsw
Switching frequency
HVG, LVG load
CL = 1 nF
800
kHz
Vcc
4
Supply Voltage
TBD
TBD
V
T
j
Junction Temperature
40
125
°C
