STFPC320
SW data
45/78
10
SW data
The SW data are read by the appropriate read command, starting from the most significant
bit. Bits 3 through 8 (b7-b2) represent the Address pointer for the internal RAM.
Figure 20.
LED byte format
10.1
Reading switch sequence
After sending this command, the STFPC320 will output a byte with the 2 bit values of the 2
switches and 6-bit address pointer values.
b0
b1
b2
b3
b4
b5
b6
b7
MSB
LSB
SW1
SW2
Address pointer for the memory
b0
b1
b2
b3
b4
b5
b6
b7
MSB
LSB
SW1
SW2
Address pointer for the memory
MSB
LSB
Data Setting Command
0
110
00
01
