Section 16 USB Function Module (USB)
Rev.1.00 Jun. 07, 2006 Page 772 of 1102
REJ09B0294-0100
16.3.21
DMA Transfer Setting Register (DMA)
DMA transfer can be carried out between the endpoint 1 and 2 data registers and memory by
means of the on-chip direct memory access controller (DMAC). Dual address transfer is
performed in bytes. To start DMA transfer, DMAC settings must be made in addition to the
settings in this register.
Bit
Bit Name
Initial Value
R/W
7
0
R
6
0
R
5
0
R
4
0
R
3
0
R
2
PULLUP_E
0
R/W
1
EP2DMAE
0
R/W
0
EP1DMAE
0
R/W
Bit
Bit Name
Initial
Value
R/W
Description
7
6
5
4
3
0
0
0
0
0
R
R
R
R
R
Reserved
These bits are always read as 0. The write value
should always be 0.
2
PULLUP_E
0
R/W
PULLUP Enable
This pin performs the pull-up control for the D+ pin,
with using PM4 as the pull-up control pin.
0: D+ is not pulled up.
1: D+ is pulled up.
