H8SX1663 データシート(PDF) 826 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX1663 データシート(HTML) 826 Page - Renesas Technology Corp |
|
|
826 / 1158 page  Section 16 USB Function Module (USB) Rev.1.00 Jun. 07, 2006 Page 774 of 1102 REJ09B0294-0100 Bit Bit Name Initial Value R/W Description 0 EP1DMAE 0 R/W Endpoint 1 DMA Transfer Enable When this bit is set, a DMAC start interrupt signal (USBINTN0) is asserted and DMA transfer is enabled from the endpoint 1 receive FIFO buffer to memory. If there is at least one byte of receive data in the FIFO buffer, the DMAC start interrupt signal (USBINTN0) is asserted. In DMA transfer, when all the received data is read, EP1 is automatically read and the completion trigger operates. EP1-related interrupt requests to the CPU are not automatically masked. • Operating procedure: 1. Write of 1 to the EP1 DMAE bit in DMA 2. Set the DMAC to activate through USBINTN0 3. Transfer count setting in the DMAC 4. DMAC activation 5. DMA transfer 6. DMA transfer end interrupt generated See section 16.8.2, DMA Transfer for Endpoint 1. |
|
