NKK Switches • email: sales@nkkswitches.com • Phone (480) 991-0942 • Fax (480) 998-1435 • www.nkkswitches.com

03-07

Ultra-Miniature SMT DIP Slides

Series JS

PACKAGING

Tape-Reel Packaging for Extended Actuator

Switches are packaged in OFF position.

Switches are not available in bulk and must

be ordered in the following increments:

JS0204AP4-R: 500 pieces per tape-reel

JS0208AP4-R: 500 pieces per tape-reel

Minimum Leader Length: 15.75” (400mm)

Minimum Trailer Length: 6.3” (160mm)

Tape-reel packaging meets EIA-481-2 Standard.

S

Stick-Tube Packaging

Switches are packaged in OFF position.

Switches are not available in bulk and must

be ordered in the following increments:

Extended Actuator

JS0204AP4-S: 46 pieces per stick-tube

JS0208AP4-S: 24 pieces per stick-tube

R

1.512

(38.4) Max

(80.0)

3.150

Dia

(32.4)

1.276

R

Typ

(2.0)

.079

(10.5)

.413

Typ

(6.5)

.256

(330.0)

13.0

Overall Dia

(12.0)

.472

(7.0)

.276

(530.0)

20.866

JS0204AP4-R JS0208AP4-R

Direction of Feed

(2.0) Dia Typ

.079

(1.5) Dia Typ

.059

(4.0) Typ

.157

(16.0) Typ

.630

(2.0) Typ

.079

(1.75)

.069

(14.25) Typ

.561

(32.0)

1.260

(6.0)

.236

(6.0)

.236

(10.3)

.406

(1.5) Typ

.059

(1.7) Typ

.067

(21.7)

.854

(0.35)

.014

3

°

(5.0)

.197

Tape Dimensions for JS0208AP4-R

Direction of Feed

(1.5) Dia Typ

.059

(1.5) Dia Typ

.059

(4.0) Typ

.157

(16.0) Typ

.630

(2.0) Typ

.079

(1.75)

.069

(11.5)

.453

(24.0)

.945

(10.3)

.406

(6.5)

.256

(2.5)

.098

(5.0)

.197

(0.35)

.014

(11.5)

.453

3

°

Tape Dimensions for JS0204AP4-R

Flush Actuator

JS0404FP4-S: 80 pieces per stick-tube

JS0408FP4-S: 45 pieces per stick-tube

Reel Dimensions

(530.0)

20.866

(11.5)

.453

(4.8)

.189

(30.4) Max

1.197

(24.4)

.961

(80.0)

3.150

Dia
