7.3

SHIPPING INSPECTION STANDARDS

7.3.1

Shipping Inspection Standards

Sampling size : MIL_STD_105D, single sampling, Inspection level II

RANK

DEFECT

AQL level

Major defect

No display

Short circuit

Outside dimensions

0.1

Minor defect

Display missing

Pattern misalignment

Spots, streaks

Bubbles

Chromaticity and uniformity

Polarizer defects

Glass defects

Dirt, spots

Current consumption

FPC

0.65

7.3.2

Zone Definitions

Shipment inspection is performed under dividing zone A and B.

7.3.3

Visual Inspection

Inspect under 30W fluorescent lamp, leaving 30cm between panel and eyes, and between

panel and lights.

7.3.4

Limit Sample

If a judgement cannot be made according to the delivery specification, limit samples must be

agreed on and used.

B Outside viewing area

A Viewing area

Display
