s Single Row In-line Socket (Full Lock Type)

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 1.The installation hole size C will be changed according to panel board thickness.

Note 2.Fabricate installation holes so that no burr can occur.

Note 3.At the panel tab portion, use the surface that will not be rounded.

Unit: mm

Part Number

CL No.

DF1B- 8ES-2.5RC

DF1B- 9ES-2.5RC

DF1B-10ES-2.5RC

DF1B-11ES-2.5RC

DF1B-12ES-2.5RC

DF1B-13ES-2.5RC

541-0326-4

541-0327-7

541-0328-0

541-0329-2

541-0330-1

541-0331-4

8

9

10

11

12

13

17.5

20

22.5

25

27.5

30

21.5

24

26.5

29

31.5

34

Yes

Number of Contacts

A

B

RoHS

Part Number

CL No.

DF1B- 2ES-2.5RC

DF1B- 3ES-2.5RC

DF1B- 4ES-2.5RC

DF1B- 5ES-2.5RC

DF1B- 6ES-2.5RC

DF1B- 7ES-2.5RC

541-0320-8

541-0321-0

541-0322-3

541-0323-6

541-0324-9

541-0325-1

2

3

4

5

6

7

2.5

5

7.5

10

12.5

15

6.5

9

11.5

14

16.5

19

Yes

Number of Contacts

A

B

RoHS

KApplicable Socket: DF1B-*DEP-2.5RC

Contact Inserted.

B Panel Cutouts

Unit: mm

Applicable Plug

Number of Contacts

DF1B- 2ES-2.5RC

DF1B- 3ES-2.5RC

DF1B- 4ES-2.5RC

DF1B- 5ES-2.5RC

DF1B- 6ES-2.5RC

DF1B- 7ES-2.5RC

DF1B- 8ES-2.5RC

DF1B- 9ES-2.5RC

DF1B-10ES-2.5RC

DF1B-11ES-2.5RC

DF1B-12ES-2.5RC

DF1B-13ES-2.5RC

2

3

4

5

6

7

8

9

10

11

12

13

0.5 to 1.2

Panel Board Thickness (Note 1)

E

10.8

13.3

15.8

18.3

20.8

23.3

25.8

28.3

30.8

33.3

35.8

38.3

1.3 to 1.6

11.3

13.8

16.3

18.8

21.3

23.8

26.3

28.8

31.3

33.8

36.3

38.8

1.7 to 2.0

12

14.5

17

19.5

22

24.5

27

29.5

32

34.5

37

39.5

C

4.7

7.2

9.7

12.2

14.7

17.2

19.7

22.2

24.7

27.2

29.7

32.2

D

6.7

9.2

11.7

14.2

16.7

19.2

21.7

24.2

26.7

29.2

31.7

34.2

Note 3

Panel
