KApplicable Socket: DF1B-*ES-2.5RC

KApplicable Socket: DF1B-*DES-2.5RC

s Single Row In-line Plug (Full Lock Type)

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Note 1.The quantity at the specific No. "None" is delivered by the bag unit (100 pcs.). If needed, please order the product per bag.

Unit: mm

Part Number

CL No.

DF1B- 8EP-2.5RC

DF1B- 9EP-2.5RC

DF1B-10EP-2.5RC

DF1B-11EP-2.5RC

DF1B-12EP-2.5RC

DF1B-13EP-2.5RC

541-0338-3

541-0339-6

541-0340-5

541-0341-8

541-0342-0

541-0343-3

8

9

10

11

12

13

23.9

26.4

28.9

31.4

33.9

36.4

17.5

20

22.5

25

27.5

30

Yes

Number of Contacts

A

B

RoHS

Part Number

CL No.

DF1B- 2EP-2.5RC

DF1B- 3EP-2.5RC

DF1B- 4EP-2.5RC

DF1B- 5EP-2.5RC

DF1B- 6EP-2.5RC

DF1B- 7EP-2.5RC

541-0332-7

541-0333-0

541-0334-2

541-0335-5

541-0336-8

541-0337-0

2

3

4

5

6

7

8.9

11.4

13.9

16.4

18.9

21.4

2.5

5

7.5

10

12.5

15

Yes

Number of Contacts

A

B

RoHS

Contact Inserted.

s Double Row In-line Plug (Full Lock Type)

Unit: mm

Part Number

CL No.

DF1B-24DEP-2.5RC

DF1B-26DEP-2.5RC

DF1B-28DEP-2.5RC

DF1B-30DEP-2.5RC

DF1B-32DEP-2.5RC

DF1B-34DEP-2.5RC

541-0372-1

541-0373-4

541-0374-7

541-0375-0

541-0376-2

541-0377-5

24

26

28

30

32

34

34.7

37.2

39.7

42.2

44.7

47.2

27.5

30

32.5

35

37.5

40

Yes

Number of Contacts

A

B

RoHS

Part Number

CL No.

DF1B-10DEP-2.5RC

DF1B-12DEP-2.5RC

DF1B-14DEP-2.5RC

DF1B-16DEP-2.5RC

DF1B-18DEP-2.5RC

DF1B-20DEP-2.5RC

DF1B-22DEP-2.5RC

541-0366-9

541-0367-1

541-0368-4

541-0369-7

541-0350-9

541-0370-6

541-0371-9

10

12

14

16

18

20

22

17.2

19.7

22.2

24.7

27.2

29.7

32.2

10

12.5

15

17.5

20

22.5

25

Yes

Number of Contacts

A

B

RoHS

Contact Inserted.
