I L 393

January 2011, Ver.03

MAXIMUM RATINGS

Symbol

Parameter

Value

Unit

VCC

Power Supply Voltages

Single Supply

Split Supplies

±18

VIDR

Input Differential Voltage Range

VICR

Input Common Mode Voltage Range (1)

-0.3 to VCC

ISC

Output Short Circuit to Ground

Continuous

IIN

Input Current, per pin (2)

Junction Temperature

Plastic Packages

150

°C

Tstg

Storage Temperature

-65 to +150

°C

Lead Temperature, 1mm from Case for 10

Seconds

260

°C

Power Dissipation @TA=25°C

Plastic Package

Derate above 25

°C

570

5.7

mW/

°C

* Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device.

These are stress ratings only and functional operation of the device at these or any other conditions beyond those

indicated under “recommended operating conditions” is not implied.

Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

Functional operation should be restricted to the Recommended Operating Conditions.

Notes:

1. Split Power Supplies.

2. VIN<-0.3V. This input current will only exist when voltage at any of the input leads is driven negative.

RECOMMENDED OPERATING CONDITIONS

Symbol

Parameter

Min

Max

Unit

VCC

DC Supply Voltage

±2.5

or 5.0

±15 or

Operating Temperature, All Package Types

-40

+85

°C

This device contains protection circuitry to guard against damage due to high static voltages or

electric fields. However, precautions must be taken to avoid applications of any voltage higher than

maximum rated voltages to this high-impedance circuit. For proper operation, VIN and VOUT should be

constrained to the range GND

≤(V

IN or VOUT)≤VCC.

Unused inputs must always be tied to an appropriate logic voltage level (e.g., either GND or VCC). Unused

outputs must be left open.
