(6/9)

INDUC

T

O

RS

20160411 / inductor_commercial_power_vlb7050_en.fm

Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.

Please note that the contents may change without any prior notice due to reasons such as upgrading.

VLB7050 Type

ELECTRICAL CHARACTERISTICS

CHARACTERISTICS SPECIFICATION TABLE

Isat: When based on the inductance change rate (20% below the nominal value)

Itemp: When based on the temperature increase (Temperature increase of 40°C by self heating)

○ Measurement equipment

＊ Equivalent measurement equipment may be used.

L

Measuring

frequency

DC resistance

Part No.

Isat

Itemp

(nH)

Tolerance

(MHz)

(m

: )

tolerance(%)

(A)typ.

(A)typ.

90

±20%

1

0.27

±6

64

36

VLB7050HT-R09M

110

±20%

1

0.27

±6

47

36

VLB7050HT-R11M

150

±20%

1

0.27

±6

37

36

VLB7050HT-R15M

Measurement item

Product No.

Manufacturer

L

4194A

Keysight Technologies

DC resistance

3541

HIOKI

Rated current Isat

3260+3265B

Wayne Kerr Electronics
