background image
Copyright © Future Technology Devices International Limited
21
FT260 HID-CLASS USB TO UART/I2C BRIDGE IC
Version 1.1
Document No.: FT_001272 Clearance No.: FTDI#484
T6
＞＝
0
input hold time requirement from SDA to SCL falling
edge when I2C as master
T7
2*(1+N)*T0
Start bit setup time to SCL falling edge
T8
4*(1+N)*T0
Start bit hold time to SCL falling edge
T9
2*(1+N)*T0
Stop bit setup time to SCL rising edge
T10
2*(1+N)*T0
Stop bit hold time to SCL rising edge
T11
4*(1+N)*T0
Bus free time between Start and Stop bit
Table 5.2 I2C Timing for VCCIO=3.3V
*Note that N can be ranged from 1 to 255
