9 / 138 page  E5GC 9 Characteristics *1. The indication accuracy of K thermocouples in the −200 to 1,300°C range, T and N thermocouples at a temperature of −100°C max., and U and L thermocouples at any temperature is ±2°C ±1 digit max. The indication accuracy of B thermocouples at a temperature of 400°C max. is not specified. The indication accuracy of B thermocouples at a temperature of 400 to 800 °C is ±3°C max. The indication accuracy of R and S thermocouples at a temperature of 200 °C max. is ±3°C ±1 digit max. The indication accuracy of C/W thermocouples is ( ±0.3% of PV or ±3°C, whichever is greater) ±1 digit max. The indication accuracy of PLII thermocouples is ( ±0.3% of PV or ±2°C, whichever is greater) ±1 digit max. *2. However, the precision between 0 and 4 mA for a 0 to 20 mA output is ±1% FS max. *3. Ambient temperature: −10°C to 23°C to 55°C, Voltage range: −15% to 10% of rated voltage *4. K thermocouple at −100°C max.: ±10°C max. *5. The unit is determined by the setting of the Integral/Derivative Time Unit parameter. *6. External serial communications (RS-485) and USB-Serial Conversion Cable communications can be used at the same time. *7. Refer to your OMRON website for the most recent information on applicable models. *8. Industrial electromagnetic environment (EN/IEC 61326-1 Table 2) Indication accuracy (at the temperature of 23 °C) Thermocouple: ( ±0.3 % of indication value or ±1°C, whichever is greater) ±1 digit max.*1 Platinum resistance thermometer: ( ±0.2 % of indication value or ±0.8°C, whichever is greater) ±1 digit max. Analog input: ±0.2% FS ±1 digit max. CT input: ±5% FS ±1 digit max. Simple transfer output accuracy ±0.3% FS max.*2 Influence of temperature *3 Thermocouple input (R, S, B, C/W, PL II): ( ±1% of indication value or ±10°C, whichever is greater) ±1 digit max. Other thermocouple input: ( ±1% of indication value or ±4°C, whichever is greater) ±1 digit max. *4 Platinum resistance thermometer: ( ±1% of indication value or ±2°C, whichever is greater) ±1 digit max. Analog input: ±1% FS ±1 digit max. CT input: ±5% FS ±1 digit max. Influence of voltage *3 Influence of EMS. (at EN 61326-1) Input sampling period 50 ms Hysteresis Temperature input: 0.1 to 999.9 °C or °F (in units of 0.1°C or °F) Analog input: 0.01% to 99.99% FS (in units of 0.01% FS) Proportional band (P) Temperature input: 0.1 to 999.9 °C or °F (in units of 0.1°C or °F) Analog input: 0.1% to 999.9% FS (in units of 0.1% FS) Integral time (I) 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5 Derivative time (D) 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5 Proportional band (P) for cooling Temperature input: 0.1 to 999.9 °C or °F (in units of 0.1°C or °F) Analog input: 0.1% to 999.9% FS (in units of 0.1% FS) Integral time (I) for cooling 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5 Derivative time (D) for cooling 0 to 9999 s (in units of 1 s), 0.0 to 999.9 s (in units of 0.1 s) *5 Control period 0.1, 0.2, 0.5, 1 to 99 s (in units of 1 s) Manual reset value 0.0% to 100.0% (in units of 0.1%) Alarm setting range −1,999 to 9,999 (decimal point position depends on input type) Influence of signal source resistance Thermocouple: 0.1 °C/Ω max. (100 Ω max.), Platinum resistance thermometer: 0.1°C/Ω max. (10 Ω max.) Insulation resistance 20 M Ω min. (at 500 VDC) Dielectric strength 100 to 240 VAC: 3,000 VAC, 50/60 Hz for 1 min between terminals of different charge 24 VAC/DC: 2,300 VAC, 50/60 Hz for 1 min between terminals of different charge Vibration Malfunction 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y and Z directions Resistance 10 to 55 Hz, 20 m/s2 for 2 hr each in X, Y, and Z directions Shock Malfunction 100 m/s2, 3 times each in X, Y, and Z directions Resistance 300 m/s2, 3 times each in X, Y, and Z directions Weight Controller: Approx. 80 g, Mounting Adapter: Approx. 4 g × 2 Degree of protection Front panel: IP66, Rear case: IP20, Terminals: IP00 Memory protection Non-volatile memory (number of writes: 1,000,000 times) Setup Tool CX-Thermo version 4.62 or higher Setup Tool port E5GC side panel: An E58-CIFQ2 USB-Serial Conversion Cable is used to connect a USB port on the computer. *6 E5GC bottom panel: An E58-CIFQ2 USB-Serial Conversion Cable and E58-CIFQ2-E Conversion Cable are used together to connect a USB port on the computer. *6 Standards Approved standards cULus: UL 61010-1/CSA C22.2 No.61010-1, Korean wireless regulations (Radio law: KC Mark) (Some models only.) *7, EAC Conformed standards EN 61010-1 (IEC 61010-1), RCM EMC EMI: EN61326-1 *8 Radiated Interference Electromagnetic Field Strength: EN55011 Group 1, class A Noise Terminal Voltage: EN55011 Group 1, class A EMS: EN61326-1 *8 ESD Immunity: EN61000-4-2 Electromagnetic Field Immunity: EN61000-4-3 Burst Noise Immunity: EN61000-4-4 Conducted Disturbance Immunity: EN61000-4-6 Surge Immunity: EN61000-4-5 Voltage Dip/Interrupting Immunity: EN61000-4-11 |
|
