E5GC

Specifications

Ratings

* There are up to four event inputs.

Power supply voltage

A in model number: 100 to 240 VAC, 50/60 Hz

D in model number: 24 VAC, 50/60 Hz; 24 VDC

Operating voltage range

85 to 110% of rated supply voltage

Power consumption

5.9 VA max. at 100 to 240 VAC, and 3.2 VA max. at 24 VAC or 1.8 W max. at 24 VDC

Sensor input

Temperature input

Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II

Platinum resistance thermometer: Pt100 or JPt100

Infrared temperature sensor (ES1B): 10 to 70

°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C

Analog input

Current input: 4 to 20 mA or 0 to 20 mA

Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V

Input impedance

Current input: 150

Ω max., Voltage input: 1 MΩ min.

(Use a 1:1 connection when connecting the ES2-HB-N/THB-N.)

Control method

ON/OFF control or 2-PID control (with auto-tuning)

Control

output

Relay output

SPST-NO, 250 VAC, 2 A (resistive load), electrical life: 100,000 operations, minimum applicable load: 5

V, 10 mA (reference value)

Voltage output

(for driving SSR)

Output voltage 12 VDC

±20% (PNP), max. Load current: 21 mA, with short-circuit protection circuit

Linear current output

4 to 20 mA DC/0 to 20 mA DC, load: 500

Ω max., resolution: Approx. 10,000

Auxiliary

output

Number of outputs

1 or 2 (depends on model)

Output specifications

SPST-NO relay outputs, 250 VAC, 2 A (resistive load),

Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference value)

Event

input

Number of inputs

1 or 2 (depends on model)

External contact input

specifications

Contact input ON: 1 k

Ω max., OFF: 100 kΩ min.

Non-contact input ON: Residual voltage 1.5 V max.; OFF: Leakage current 0.1 mA max.

Current flow: approx. 7 mA per contact

Setting method

Digital setting using front panel keys

Indication method

11-segment digital displays and individual indicators

Character height: PV: 10.5 mm, SV: 5.0 mm

Multi SP

Up to eight set points (SP0 to SP7) can be saved and selected using the event inputs, key operations, or

serial communications.

Bank switching

None

Other functions

Manual output, heating/cooling control, loop burnout alarm, SP ramp, other alarm functions, heater

burnout (HB) alarm (including SSR failure (HS) alarm), 40% AT, 100% AT, MV limiter, input digital filter,

self tuning, robust tuning, PV input shift, run/stop, protection functions, extraction of square root, MV

change rate limit, logic operations, temperature status display, simple programming, moving average of

input value, display brightness setting, simple transfer output, and work bit message

Ambient operating temperature

−10 to 55°C (with no condensation or icing), For 3-year warranty: −10 to 50°C with standard mounting (with

no condensation or icing)

Ambient operating humidity

25 to 85%

Storage temperature

−25 to 65°C (with no condensation or icing)

Altitude

2,000 m max.

Recommended fuse

T2A, 250 VAC, time-lag, low-breaking capacity

Installation environment

Overvoltage category II, Pollution Degree 2 (EN/IEC/UL 61010-1)
