598 / 1158 page  Section 10 16-Bit Timer Pulse Unit (TPU) Rev.1.00 Jun. 07, 2006 Page 546 of 1102 REJ09B0294-0100 • When TGR is an input capture register When input capture occurs, the value in TCNT is transferred to TGR and the value previously held in TGR is transferred to the buffer register. This operation is illustrated in figure 10.13. Buffer register Timer general register TCNT Input capture signal Figure 10.13 Input Capture Buffer Operation (1) Example of Buffer Operation Setting Procedure Figure 10.14 shows an example of the buffer operation setting procedure. Select TGR function Buffer operation Set buffer operation Start count <Buffer operation> [1] [2] [3] [1] Designate TGR as an input capture register or output compare register by means of TIOR. [2] Designate TGR for buffer operation with bits BFA and BFB in TMDR. [3] Set the CST bit in TSTR to 1 to start the count operation. Figure 10.14 Example of Buffer Operation Setting Procedure |
|
