640 / 1158 page  Section 11 Programmable Pulse Generator (PPG) Rev.1.00 Jun. 07, 2006 Page 588 of 1102 REJ09B0294-0100 • PODRL Bit Bit Name Initial Value R/W Description 7 6 5 4 3 2 1 0 POD7 POD6 POD5 POD4 POD3 POD2 POD1 POD0 0 0 0 0 0 0 0 0 R/W R/W R/W R/W R/W R/W R/W R/W Output Data Register 7 to 0 For bits which have been set to pulse output by NDERL, the output trigger transfers NDRL values to this register during PPG operation. While NDERL is set to 1, the CPU cannot write to this register. While NDERL is cleared, the initial output value of the pulse can be set. 11.3.3 Next Data Registers H, L (NDRH, NDRL) NDRH and NDRL store the next data for pulse output. The NDR addresses differ depending on whether pulse output groups have the same output trigger or different output triggers. • NDRH Bit Bit Name Initial Value R/W 7 NDR15 0 R/W 6 NDR14 0 R/W 5 NDR13 0 R/W 4 NDR12 0 R/W 3 NDR11 0 R/W 2 NDR10 0 R/W 1 NDR9 0 R/W 0 NDR8 0 R/W • NDRL Bit Bit Name Initial Value R/W 7 NDR7 0 R/W 6 NDR6 0 R/W 5 NDR5 0 R/W 4 NDR4 0 R/W 3 NDR3 0 R/W 2 NDR2 0 R/W 1 NDR1 0 R/W 0 NDR0 0 R/W |
|
