SH7708 データシート(PDF) 73 Page - Renesas Technology Corp

部品番号 SH7708
部品情報  SuperH??RISC engine
PDF  633 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
メーカー  RENESAS [Renesas Technology Corp]
ホームページ  http://www.renesas.com
Logo RENESAS - Renesas Technology Corp

SH7708 データシート(HTML) 73 Page - Renesas Technology Corp

Back Button SH7708 Datasheet HTML 69Page - Renesas Technology Corp SH7708 Datasheet HTML 70Page - Renesas Technology Corp SH7708 Datasheet HTML 71Page - Renesas Technology Corp SH7708 Datasheet HTML 72Page - Renesas Technology Corp SH7708 Datasheet HTML 73Page - Renesas Technology Corp SH7708 Datasheet HTML 74Page - Renesas Technology Corp SH7708 Datasheet HTML 75Page - Renesas Technology Corp SH7708 Datasheet HTML 76Page - Renesas Technology Corp SH7708 Datasheet HTML 77Page - Renesas Technology Corp Next Button
Zoom Inzoom in Zoom Outzoom out
 73 / 633 page
background image
55
H'80000000
H'A0000000
H'C0000000
H'E0000000
H'FFFFFFFF
2-Gbyte virtual space,
cacheable
(write-back/write-through)
2-Gbyte virtual space,
cacheable
(write-back/write-through)
Address error
H'00000000
H'00000000
H'80000000
H'FFFFFFFF
Area P0
Area P1
Area P2
Area P3
Area P4
Area U0
Privileged mode
User mode
H'7F000000
H'7F000000
On-chip RAM space
0.5-Gbyte fixed physical
space, cacheable
(write-through: SH7708)
0.5-Gbyte fixed
physical space,
non-cacheable
0.5-Gbyte virtual space,
cacheable
(write-back/write-through)
0.5-Gbyte control space,
non-cacheable
On-chip RAM space
(write-back/write-through:
SH7708S, SH7708R)
Figure 3.2 Virtual Address Space Mapping
