Low-Power, Multifunction, Polyphase AFE
with Harmonics and Tamper Detect
78
______________________________________________________________________________________
DSP System Configuration
System Clock Frequency (SYS_KHZ) (0x012)
This register contains the system clock frequency in kHz units. Because the default frequency is 8MHz, this register
defaults to 0x1F40.
Cycle Count (CYCNT) (0x01C)
This register contains the number of line cycles that will be accumulated in a single DSP cycle. When CYCNT line
cycles have been accumulated, the DSP performs power, power factor, and energy calculations. By default, the
cycle count is 0x10 (16 decimal).
Bit:
15
14
13
12
11
10
9
8
Name:
Cycle Count High Byte
Reset:
0x00
Bit:
7
6
5
4
3
2
1
0
Name:
Cycle Count Low Byte
Reset:
0x10
Bit:
15
14
13
12
11
10
9
8
Name:
System Clock Frequency High Byte
Reset:
0x1F
Bit:
7
6
5
4
3
2
1
0
Name:
System Clock Frequency Low Byte
Reset:
0x40
