background image
Si3226/7
Si3208/9
Preliminary Rev. 0.33
29
5. Pin Descriptions: Si3226/7
Table 17. Si3226/7 Pin Descriptions
Pin
Number
Symbol
I/O
Description
1
SRINGDCa
I
RING DC Sense Input.
2
SRINGACa
I
RING AC Sense Input.
3
STIPACa
I
TIP AC Sense Input.
4
STIPDCa
I
TIP DC Sense Input.
5
CAPPa
I/O
Metallic Loop Filter Capacitor-Positive Terminal.
6
CAPMa
I/O
Metallic Loop Filter Capacitor-Negative Terminal.
7
SVBATa
I
Battery Sensing Input.
8
SVDC
I
DC-DC Input Power Rail Sensor.
9
GPIO3a / PWROa
I/O
General Purpose I/O / Power Offloading Output.
10
GPIO2a / SRINGCa /
TRD2a
I/O
General Purpose I/O / TIP Course Sense Input / Test Relay
Driver.
11
GPIO1a / STIPCa / TRD1a
I/O
General Purpose I/O / TIP Course Sense Input / Test Relay
Driver.
12
CS
I
Chip Select Input.
13
FSYNC
I
Frame Sync Clock Input.
14
SDI
I
Serial Port Data Input.
15
HVCLKa
O
Line-Driver IC Clock Output.
16
SCLK
I
Serial Port Bit Clock Input.
17
HVDATA
O
Line-Driver IC Data Output
18
SDITHRU
O
Serial Data Daisy Chain Output.
19
SDO
O
Serial Port Data Output.
20
DCFFa
I/O
DC-DC BJT Drive Monitor.
21
SDCHa
I
DC-DC Current Monitor Input-High Terminal.
22
SDCLa
I
DC-DC Current Monitor Input-Low Terminal.
23
DCDRVa
I/O
DC-DC Drive Output.
24
VDDC
PWR
DC-DC Switch Driver Power Supply.
25
DCDRVb
O
DC-DC Drive Output.
26
SDCLb
I
DC-DC Current Monitor Input-Low Terminal.
27
SDCHb
I
DC-DC Current Monitor Input-High Terminal.
28
DCFFb
I/O
DC-DC BJT Drive Monitor.
29
GNDD
GND
Digital Ground.
30
VDDD
PWR
Digital Supply Voltage.
31
PCLK
I
PCM Bus Clock Input.
32
HVCLKb
O
Line-Driver IC Clock Output.
