Si3226/7
Si3208/9
Preliminary Rev. 0.33
31
6. Pin Descriptions: Si3208/9
Table 18. Si3208/9 Pin Descriptions
QFN Pin #
Symbol
I/O
Description
1
IC
Internal connection; leave to float.
2
NC
No Connect.
3
RING_1
I/O
Ring Channel 1 Input/Output.
4
NC
No Connect.
5
TIP_1
I/O
Tip Channel 1 Input/Output.
6
NC
No Connect.
7
IC
Internal connection; leave to float.
8
IRINGN_1
I
Negative Ring Current Control Channel 1 Input.
9
IRINGP_1
I
Positive Ring Current Control Channel 1 Input.
10
ITIPN_1
I
Negative Tip Current Control Channel 1 Input.
11
ITIPP_1
I
Positive Tip Current Control Channel 1 Input.
12
IBIAS_1
I
Current Bias Channel 1 Input.
13
ISNS
O
Current Sense Output.
14
VDD
I
IC Supply Voltage Input.
15
HVCLK_1
I
High-Voltage IC Clock Channel 1 Input.
16
HVDATA
I/O
High-Voltage IC Data Input/Output.
17
HVCLK_2
I
High-Voltage IC Clock Channel 2 Input.
18
DGND
I
Digital Ground.
19
IBIAS_2
I
Current Bias Channel 2 Input.
20
ITIPP_2
I
Positive Tip Current Control Channel 1 Input.
21
ITIPN_2
I
Negative Tip Current Control Channel 2 Input.
22
IRINGP_2
I
Positive Ring Current Control Channel 2 Input.
23
IRINGN_2
I
Negative Ring Current Control Channel 2 Input.
24
IC
Internal connection; leave to float.
25
NC
No Connect.
26
TIP_2
I/O
Tip Channel 2 Input/Output.
27
NC
No Connect.
28
RING_2
I/O
Ring Channel 2 Input/Output.
29
NC
No Connect.
30
IC
Internal connection; leave to float.
31
IC
Internal connection; leave to float.
32
VBAT_2
I
Operating Battery Voltage Channel 2 Input.
33
NC
No Connect.
34
IC
Internal connection; leave to float.
