Section 9 I/O Ports
Rev.1.00 Jun. 07, 2006 Page 446 of 1102
REJ09B0294-0100
9.2.2
Port 2
(1) P27/PO7/TIOCA5/TIOCB5
The pin function is switched as shown below according to the combination of the TPU and PPG
register settings and P27DDR bit setting.
Setting
TPU
PPG
I/O Port
Module Name
Pin Function
TIOCB5_OE
PO7_OE
P27DDR
TPU
TIOCB5 output
1
—
—
PPG
PO7 output
0
1
—
P27 output
0
0
1
I/O port
P27 input
(initial setting)
0
0
0
(2) P26/PO6/TIOCA5/TMO1/TxD1
The pin function is switched as shown below according to the combination of the TPU, TMR,
SCI, and PPG register settings and P26DDR bit setting.
Setting
TPU
TMR
SCI
PPG
I/O Port
Module Name
Pin Function
TIOCA5_OE TMO1_OE
TxD1_OE
PO6_OE
P26DDR
TPU
TIOCA5 output
1
TMR
TMO1 output
0
1
SCI
TxD1 output
0
0
1
PPG
PO6 output
0
0
0
1
P26 output
0
0
0
0
1
I/O port
P26 input
(initial setting)
0
0
0
0
0
