1 / 27 page

This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to

change without notice.

June 2012

Doc ID 022743 Rev 1

1/27

27

TSV521, TSV522, TSV524,

TSV521A, TSV522A, TSV524A

High merit factor (1.15 MHz for 45 µA) CMOS op amps

Datasheet

−preliminary data

Features

■ Gain bandwidth product: 1.15 MHz typ. at 5 V

■ Low power consumption: 45 µA typ. at 5 V

■ Rail-to-rail input and output

■ Low input bias current: 1 pA typ.

■ Supply voltage: 2.7 to 5.5 V

■ Low offset voltage: 800 µV max.

■ Unity gain stable on 100 pF capacitor

■ Automotive grade

Benefits

■ Increased lifetime in battery powered

applications

■ Easy interfacing with high impedance sensors
