TMS320C31, TMS320LC31

DIGITAL SIGNAL PROCESSORS

SPRS035B – MARCH 1996 – REVISED JANUARY 1999

POST OFFICE BOX 1443

• HOUSTON, TEXAS 77251–1443

memory map (continued)

FSX/DX/CLKX Serial Port Control

FSR/DR/CLKR Serial Port Control

Serial R/X Timer Control

Serial R/X Timer Counter

Serial R/X Timer Period Register

Data-Transmit

Data-Receive

Primary-Bus Control

DMA Global Control

DMA Source Address

DMA Destination Address

DMA Transfer Counter

Timer 0 Global Control

Timer 0 Counter

Timer 0 Period Register

Timer 1 Global Control

Timer 1 Counter

Timer 1 Period Register

Serial Global Control

808000h

808004h

808006h

808008h

808020h

808024h

808028h

808030h

808034h

808038h

808040h

808042h

808043h

808044h

808045h

808046h

808048h

80804Ch

808064h

†Shading denotes reserved address locations

Figure 3. Peripheral Bus Memory-Mapped Registers†
