3.3.2 Specifications for 1.8V I/Os

Note 1 : X is the source/sink current under worst case conditions according to the drive capability. (See table 8, pad information for value of X).

3.4 Current Consumption

Table 7. Typical power consumption of the STLC2410B and External Flash using UART (VDD =

VDD Flash = PLLVDD = 1.8V, VDDIO = 3.3V)

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

Low level input voltage

V

High level input voltage

V

Schmitt trigger hysteresis

0.2

0.3

0.5

V

Symbol

Parameter

Conditions

Min

Typ

Max

Unit

Note

Low level output voltage

0.15

V

1

High level output voltage

V

1

STLC2410B State

Core

IO

Unit

Slave

Master

Standby (no low power mode)

5.10

5.10

0.13

mA

Standby (low power mode enabled)

0.94

0.94

0.13

mA

ACL connection (no transmission)

7.60

6.99

0.13

mA

ACL connection (data transmission)

7.90

7.20

0.13

mA

SCO connection (no codec connected)

8.70

7.90

0.14

mA

Inquiry and Page scan (low power mode enabled)

127

n.a.

5

µA

Low Power mode (32 kHz crystal)

20

20

0

µA
