R3111Q552B datasheet(3/43 Pages) NISSHINBO

3 / 43 page

R3111x

 R3111E (TO-92) is the discontinued product as of April, 2017.

SELECTION GUIDE

The package type, the detector threshold, the output type and the taping type for the ICs can be selected at

the users’ request. The selection can be made with designating the part number as shown below;

Product Name

Package

Quantity per Reel

Pb Free

Halogen Free

R3111Dxx1

-TR-FE

SON1612-6

4,000 pcs

Yes

R3111Qxx1

-TR-FE

SC-82AB

3,000 pcs

Yes

R3111Qxx2

-TR-FE

SC-88A

3,000 pcs

Yes

R3111Nxx1

-TR-FE

SOT-23-5

3,000 pcs

Yes

R3111Nxx2$-TR-FE

SOT-23-3

3,000 pcs

Yes

R3111Hxx1$-T1-FE

SOT-89

1,000 pcs

Yes

R3111Exx1$-TZ-F

TO-92

2,500 pcs

Yes

xx: The detector threshold can be designated in the range from 0.9V(09) to 6.0V(60) in 0.1V steps.

(For other voltages, please refer to MARK INFORMATIONS.)

 : Designation of Output Type

(A) Nch Open Drain (Output "L" at Detection)

(B) Nch Open Drain (Output "H" at Detection)

$ : Designation of Output Type

(A) Nch Open Drain (Output "L" at Detection)
