AK8180D

MS1306-E-01

Oct-2011

- 9 -

Function Table

The following table shows the inputs/outputs clock state configured through the control pins.

Table 1: Control-Pin-Setting Function Table

Control Pin

Default

0

1

DSELA

0

QA0-2 = REFCLK x 1

QA0-2 = REFCLK x 1/2

DSELB

0

QB0-2 = REFCLK x 1

QB0-2 = REFCLK x 1/2

DSELC

0

QC0-3 = REFCLK x 1

QC0-3 = REFCLK x 1/2

OE

MR/

0

Output enabled

Internal reset. Outputs disabled.

(High impedance)
