AD9397

Rev. 0 | Page 21 of 28

0x30—Bit[6] DVI Content Encrypted

This read-only bit is high when HDCP decryption is in use

(content is protected). The signal goes low when HDCP is not

being used. Customers can use this bit to allow copying of the

content. The bit should be sampled at regular intervals because

it can change on a frame-by-frame basis. 0 = HDCP not in use.

1 = HDCP decryption in use.

0x30—Bit[5] DVI HSYNC Polarity

This read-only bit indicates the polarity of the DVI HSYNC. 0 =

DVI HSYNC polarity is low active. 1 = DVI HSYNC polarity is

high active.

0x30—Bit[4] DVI VSYNC Polarity

This read-only bit indicates the polarity of the DVI VSYNC.

0 = DVI VSYNC polarity is low active. 1 = DVI VSYNC polarity

is high active.

MACROVISION

0x31—Bits[7:4] Macrovision Pulse Max

These bits set the pseudo sync pulse width maximum for

Macrovision detection in pixel clocks. This is functional for

13.5 MHz SDTV or 27 MHz progressive scan. Power-up

default is 9.

0x31—Bits[3:0] Macrovision Pulse Min

These bits set the pseudo sync pulse width maximum for

Macrovision detection in pixel clocks. This is functional for

13.5 MHz SDTV or 27 MHz progressive scan. Power up

default is 6.

0x32—Bit[7] Macrovision Oversample Enable

Tells the Macrovision detection engine whether oversampling

is used. This accommodates 27 MHz sampling for SDTV and

54 MHz sampling for progressive scan and is used as a

correction factor for clock counts. Power-up default is 0.

0x32—Bit[6] Macrovision PAL Enable

Tells the Macrovision detection engine to enter PAL mode when

set to 1. Default is 0 for NTSC mode.

0x32—Bits[5:0] Macrovision Line Count Start

Set the start line for Macrovision detection. Along with

pulses are expected to occur. The power-up default is Line 13.

0x33—Bit[7] Macrovision Detect Mode

0 = standard definition. 1 = progressive scan mode

0x33—Bit[6] Macrovision Settings Override

This defines whether preset values are used for the MV line

counts and pulse widths or the values stored in I2C registers are

used. 0 = use hard-coded settings for line counts and pulse

widths. 1 = use I2C values for these settings.

0x33—Bits[5:0] Macrovision Line Count End

Set the end line for Macrovision detection. Along with Register

0x32, Bits [5:0], they define the region where MV pulses are

expected to occur. The power-up default is Line 21.

0x34—Bits[7:6] Macrovision Pulse Limit Select

Set the number of pulses required in the last three lines (SD

mode only). If there is not at least this number of MV pulses,

the engine stops. These two bits define these pulse counts:

00 = 6.

01 = 4.

10 = 5 (default).

11 = 7.

0x34—Bit[5] Low Frequency Mode

Sets whether the audio PLL is in low frequency mode or not.

Low frequency mode should only be set for pixel clocks

<80 MHz.

0x34—Bit[4] Low Frequency Override

Allows the previous bit to be used to set low frequency mode

rather than the internal autodetect.

0x34—Bit[3] Upconversion Mode

0 = repeat Cb/Cr values. 1 = interpolate Cb/Cr values.

0x34—Bit[2] CbCr Filter Enable

Enables the FIR filter for 4:2:2 CbCr output.

COLOR SPACE CONVERSION

The default power-up values for the color space converter

coefficients (R0x35 through R0x4C) are set for ATSC RGB-to-

YCbCr conversion. They are completely programmable for

other conversions.

0x34—Bit[1] Color Space Converter Enable

This bit enables the color space converter. 0 = disable color

space converter. 1 = enable color space converter. The power-up

default setting is 0.

0x35—Bits[6:5] Color Space Converter Mode

These two bits set the fixed-point position of the CSC

coefficients, including the A4, B4, and C4 offsets. Default = 01.

Table 14. CSC Fixed Point Converter Mode

Select

Result

±1.0, −4096 to +4095

±2.0, −8192 to +8190

1×

±4.0, −16384 to +16380
