ADL5385ACPZ-R7 データシート(PDF) 4 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADL5385ACPZ-R7 データシート(HTML) 4 Page - Analog Devices |
|
|
4 / 24 page  ADL5385 Data Sheet Rev. D | Page 4 of 24 Parameter Test Conditions/Comments Min Typ Max Unit OUTPUT FREQUENCY = 140 MHz Output Power Single (lower) sideband output 5.7 dBm Output P1 dB 11 dBm Carrier Feedthrough Unadjusted (nominal drive level) −52 dBm +85°C after optimization at +25°C −66 dBm −40°C after optimization at +25°C −67 dBm Sideband Suppression Unadjusted (nominal drive level) −53 dBc +85°C after optimization at +25°C −63 dBc −40°C after optimization at +25°C −68 dBc Second Baseband Harmonic (fLO − (2 × fBB)), POUT = 5 dBm −83 dBc Third Baseband Harmonic (fLO + (3 × fBB)), POUT = 5 dBm −57 dBc Output IP2 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 70 dBm Output IP3 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT =−3 dBm per tone 26 dBm Quadrature Phase Error −0.33 Degrees I/Q Amplitude Balance −0.03 dB Noise Floor 20 MHz offset from LO, all BB inputs at a bias of 500 mV −160 dBm/Hz Output Return Loss −20 dB OUTPUT FREQUENCY = 350 MHz Output Power Single (lower) sideband output 3 5.6 7 dBm Output P1 dB 11 dBm Carrier Feedthrough Unadjusted (nominal drive level) −46 dBm +85°C after optimization at +25°C −65 dBm −40°C after optimization at +25°C −66 dBm Sideband Suppression Unadjusted (nominal drive level) −50 dBc +85°C after optimization at +25°C −63 dBc −40°C after optimization at+25°C −61 dBc Second Baseband Harmonic (fLO − (2 × fBB)), POUT = 5 dBm −80 dBc Third Baseband Harmonic (fLO + (3 × fBB)), POUT = 5 dBm −53 dBc Output IP2 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 71 dBm Output IP3 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 26 dBm Quadrature Phase Error 0.39 Degrees I/Q Amplitude Balance −0.03 dB Noise Floor 20 MHz offset from LO, all BB inputs at a bias of 500 mV −159 dBm/Hz 20 MHz offset from LO, output power = −5 dBm −157 dBm/Hz Output Return Loss −21 dB OUTPUT FREQUENCY = 860 MHz Output Power Single (lower) sideband output 2.5 5.3 6.5 dBm Output P1 dB 11 dBm Carrier Feedthrough Unadjusted (nominal drive level) −41 −35 dBm +85°C after optimization at +25°C −63 dBm −40°C after optimization at +25°C −65 dBm Sideband Suppression Unadjusted (nominal drive level) −41 −35 dBc +85°C after optimization at +25°C −58 dBc −40°C after optimization at +25°C −59 dBc Second Baseband Harmonic (fLO − (2 × fBB)), POUT = 5 dBm −73 −57 dBc Third Baseband Harmonic (fLO + (3 × fBB)), POUT = 5 dBm −50 −45 dBc Output IP2 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 70 dBm Output IP3 F1 = 3.5 MHz, F2 = 4.5 MHz, POUT = −3 dBm per tone 25 dBm Quadrature Phase Error 0.67 Degrees I/Q Amplitude Balance −0.03 dB |
|
|
