ADL5385ACPZ-R7 datasheet(6/24 Pages) AD

6 / 24 page

ADL5385

Data Sheet

Rev. D | Page 6 of 24

Parameter

Test Conditions/Comments

Min

Typ

Max

Unit

Noise Floor

20 MHz offset from LO, all BB inputs at a bias of 500 mV

−160

dBm/Hz

20 MHz offset from LO, output power = −5 dBm

−156

dBm/Hz

Output Return Loss

−15

LO INPUTS

Pin LOIP and Pin LOIN

LO Drive Level

Characterization performed at typical level

−10

–7

dBm

fOUT < 50 MHz

dBm

Input Impedance

Ω

Input Return Loss

350 MHz, LOIN ac-coupled to ground

−20

BASEBAND INPUTS

Pin IBBP, Pin IBBN, Pin QBBP, Pin QBBN

I and Q Input Bias Level

500

Input Bias Current

−70

µA

Bandwidth (0.1 dB)

RF = 500 MHz, output power = 0 dBm

MHz

Bandwidth (3 dB)

RF = 500 MHz, output power = 0 dBm

>500

MHz

ENABLE INPUT

ENBL

Turn-On Settling Time

ENBL = high (for output to within 0.5 dB of final value)

1.0

µs

Turn-Off Settling Time

ENBL = low (at supply current falling below 20 mA)

1.4

µs

ENBL High Level (Logic 1)

1.5

ENBL Low Level (Logic 0)

0.4

TEMPERATURE OUTPUT

TEMP

Output Voltage

TA = 27.15°C, 300.3 K, RL = 1 MΩ (after full warm up)

1.56

Temperature Slope

−40°C ≤ TA ≤ +85°C, RL = 1 MΩ

4.6

mV/°C

Output Impedance

1.0

kΩ

POWER SUPPLIES

Pin VPS1 and Pin VPS2

Voltage

4.75

5.5

Supply Current

ENBL = high

215

240

ENBL = low

µA
