64 / 83 page  1.8V Uniform Sector Dual and Quad Serial Flash GD25LE256D 64 Table3. Signature and Parameter Identification Data Values Description Comment Add(H) (Byte) DW Add (Bit) Data Data SFDP Signature Fixed:50444653H 00H 07:00 53H 53H 01H 15:08 46H 46H 02H 23:16 44H 44H 03H 31:24 50H 50H SFDP Minor Revision Number Start from 00H 04H 07:00 00H 00H SFDP Major Revision Number Start from 01H 05H 15:08 01H 01H Number of Parameters Headers Start from 00H 06H 23:16 01H 01H Unused Contains 0xFFH and can never be changed 07H 31:24 FFH FFH ID number (JEDEC) 00H: It indicates a JEDEC specified header 08H 07:00 00H 00H Parameter Table Minor Revision Number Start from 0x00H 09H 15:08 00H 00H Parameter Table Major Revision Number Start from 0x01H 0AH 23:16 01H 01H Parameter Table Length (in double word) How many DWORDs in the Parameter table 0BH 31:24 09H 09H Parameter Table Pointer (PTP) First address of JEDEC Flash Parameter table 0CH 07:00 30H 30H 0DH 15:08 00H 00H 0EH 23:16 00H 00H Unused Contains 0xFFH and can never be changed 0FH 31:24 FFH FFH ID Number LSB (GigaDevice Manufacturer ID) It is indicates GigaDevice manufacturer ID 10H 07:00 C8H C8H Parameter Table Minor Revision Number Start from 0x00H 11H 15:08 00H 00H Parameter Table Major Revision Number Start from 0x01H 12H 23:16 01H 01H Parameter Table Length (in double word) How many DWORDs in the Parameter table 13H 31:24 03H 03H Parameter Table Pointer (PTP) First address of GigaDevice Flash Parameter table 14H 07:00 60H 60H 15H 15:08 00H 00H 16H 23:16 00H 00H Unused Contains 0xFFH and can never be changed 17H 31:24 FFH FFH |
|
